Nedo wooden tripods are made of carefully selected European ash wood. All wooden parts are sealed with a high-tech plastic material that keeps moisture out. This ensures that there is no swelling, shrinking or splintering of wood and it makes Nedo wooden tripods extremely robust and weatherproof. Nedo wooden tripods are more durable than tripods with regular lacquering.
Features:
- Wooden parts made of finest European hard wood
- Plastic-coated wooden legs for utmost durability
- Large round tripod head made of aluminum, powder-coated
- Dual clamp: quick release and screw clamp
- Break-proof quick release levers, made of aluminum
- Snap Cap
- Brass hinge pins for extra stability
- Tripod feet made of aluminum w/ replaceable steel points
- Carrying strap
- In accordance with ISO 12858-2-H
- Strapless-Go leg locking system without a strap
Specifications:
|
Min. effective height
|
approx. 3'4" / 1.00 m |
| Max. effective height |
approx. 5'7" / 1.70 m |
| Retracted length |
approx. 3'8" / 1.10 m |
| Holding screw |
5/8’’ x 11 thread |
| Weight |
17 lbs. 7.70 kg |
| Tripod head |
flat, ø 6.5" / 167 mm |
Suitable for: Total Stations, Robotic Total Stations, Digital Levels, Theodolites and Heavy-Duty Rotating Lasers
Strapless-Go Leg Locking System:
Many light and medium-weight Nedo aluminium tripods and elevating tripods are equipped with the new Strapless-Go leg locking system without a strap. The tripod legs snap together automatically when they are pushed in. It’s quick and convenient. No more troublesome strapping to hold legs in place for transport.
To release the lock, simply pull out the leg with the printed marking. The legs immediately unlock and you can set up the tripod.
Strapless-Go - quick, easy, maximum comfort
